Single channel Loop Detector - PSA02
Single channel Loop Detector - PSA02

Single channel Loop Detector - PSA02

$0.00

Single channel Loop Detector - PSA02

Features:
Power Voltage : 220VAC±10% 50/60Hz 24VAC/DC±10%,
Sensing range : 20~1500uH,
Sensitivity : 0.02%~0.2% (7degress selections),
Reaction time : 50ms.

(Available)
Quantity

SKU: MF-2443-AELQW

Categories: Loop Detector - PSA02

Share:

Technical Specifications

  • Power Voltage : 220VAC±10% 50/60Hz 24VAC/DC±10%
  • Sensing range : 20~1500uH
  • Sensitivity : 0.02%~0.2% (7degress selections)
  • Reaction time : 50ms
  • Frequency : 2 degrees selections, 15~120kHz
  • Output : 2 output relays (5A/AC230V), Relay1: presence relay, Relay2: pulse/fault relay
  • Operating mode Mode1 : presence& pulse relay output , Mode2: pulse/ fault relay
  • Presence mode : Limited presence/ permanent presence
  • Pulse mode : Pulse entry/ pulse exit
  • Pulse output time : Pulse entry: 200ms , Pulse exit: 200ms
  • Presence time : Limited presence , 30min/ permanent presence
  • Indicator Power indicator : red LED , Status indicator: green LED
  • Internal protection : Isolation transformer, voltage Regulator tube, voltage Dependent resistor.
  • Operating temp : -40℃~80℃.
