UHF1-Tag4
UHF1-Tag4

UHF1-Tag4

$0.00

Ultra High Frequency Tag

Features:
Working Frequency : 860~960MHz ,
Working Mode : Passive (no battery) ,
Data Storage Period : 10 Years ,
Working Temperature : 0~60℃ ,
Chip : Alien H3

(Available)
Quantity

SKU: MF-2443-PWHUW

Categories: UHF1-Tag4

Share:

Feature

  • High Safety
  • Long Service Life
  • High Reading Rate
  • High Chip Sensitivity
  • Flexible Storage Structure
  • Reading and Writing Repeatedly
  • Adhesive Design, Easy Installation
  • Anti-tear: when torn, it will be destroyed

Technical Specifications

  • Working Frequency : 860MHz~960MHz
  • Reading Distance : Up to 10 meters for UHF1-10E and UHF1-10F (Determined by the environment and reader) Protocol Standard : ISO/IEC 18000-6C, EPC global Class 1 Gen 2
  • Chip : Alien H3
  • Working Mode : Passive (no battery)
  • Storage Structure : EPC: 96bits, UID/TID: 64bits, User: 512bits Kill Password: 32bits, Access Password: 32bits
  • Erase Endurance : 100,000 Times
  • Data Storage Period : 10 Years
  • Working Temperature : 0~60℃
  • Storage Humidity : 20%~60% RH
  • Immunity Against Electrostatic Voltage : 2 KV (HBM)
  • Curvature : > 60mm
  • Dimension : 96.5x23.2 (mm) ±0.5(mm)
  • Installation : Stick on the windshield ( Parking Applications )

Typical Applications

  • Goods Management
  • Vehicle Management
  • Highway (Bridge) Toll Collection Management
